Advantages:
1. Long service life, cost-saving.2.The coating is highly shiny.
3.High hardness, excellent wear resistance.
Coating Characteristics:
Density : 8.1 g/cm³
Phosphorus content : 6-9%
Hardness: 525-600 HK100
850-950 HK100 (400℃, 1 hour of heat treatment)
Wear resistance: 16-20 TWI 10-14WI (400℃, 1 hour of heat treatment)
Magnetic: micro-magnetic
Impedance: 70-110 μΩ/cm
Salt spray >96 (ASTM B117, plating layer thickness 25.4μm)
The Concentration for Making Up New Bath:
FF-6000A 50ml/L
FF-6000B 150ml/L
Operating Conditions:
|
|
Range |
Optimal |
|
Nickel Metal |
5.4~6.3g/L 90~105% activity |
6.0g/L 100% activity |
|
Reducer (contains in FF-6000B and FF-6000D) |
27~33 g/L 90~110% activity |
30g/L 100% activity |
|
Temperature |
85~91℃ |
88℃ |
|
PH |
4.7~5.2 |
5.0 |
|
Plating Speed |
15~20μm/hr |
18μm/hr |
|
Loading Capacity |
0.25~2.5dm²/ L |
1.2dm²/L |
