Name: Fengfan Alkaline Zinc Nickel Alloy Process Zinc Nickel Alloy Plating Process Eco Zinie 300
Brand: Fengfan International Trade
Availability: InStock
Rating: 5 (1 reviews)

Description

Eco-Zinie 300 alkaline Zinc-nickel alloy process

I. Product Characteristics

It is alkaline high-corrosion plating process, environment-friendly, which meets the needs of European and American automotive industry.
With a wide range of current density and high efficiency, and the zinc-nickel alloy layer contains 11~16% nickel content.
Good process dispersion and homogeneous plating ability, uniform deposit distribution, excellent metal distribution and constant alloy composition.
The layer color is white and bright , good ductility, easy maintenance, suitable for rack and barrel plating process.
The plating bath is easy to maintain, if used with matched passivating agent, can get high corrosion resistance and good thermal-shock resistance.

Ⅱ.Process Flow:

Alkaline chemical degreasing → Washing → Acid degreasing → Cleaning → Activation → Cleaning → Zinc-nickel alloy plating process → Cleaning → Get bright (dilute hydrochloric acid solution pH=3.5~4.0) → Cleaning → Passivation → Cleaning → Sealing → Dry curing

Ⅲ. Process Formula and Operating Conditions

Product Name	Operating Range	Optimal (rack plating)	Optimal (barrel plating)
Zinc metal(Zn2＋)	5.0~10.0g/L	7.0g/L	9.0g/L
NaOH	110~135g/L	120g/L	130g/L
Eco-Zinie 300 MU	4~12ml/L	8ml/L	10ml/L
Eco-Zinie 300 A complex agent	90~120ml/L	100ml/L	110ml/L
Eco-Zinie 300 B brightener	0.5~2ml/L	1ml/L	1ml/L
Eco-Zinie 300 Cnickel supplement	12~16ml/L	13ml/L	15ml/L
Temperature(℃)	23~28℃	26±2℃	26±2℃
Cathode current density(Dk)	0.5~4A/dm2
Anode	Nickel plate (or special insoluble anode)
Filtration	Continuous filtration, 1-2 cycles/hour

Alkaline System Compatibility with Stable Alloy Output
Eco Zinie 300 is an alkaline-based zinc-nickel alloy plating process developed for operations requiring consistent and controlled alloy deposition. It is designed to function effectively in systems that prioritize bath stability and efficient metal distribution. This formulation achieves reliable coverage and a uniform zinc-nickel layer across various substrate surfaces. It is well-suited to metal plating service workflows where alkaline chemistry is preferred for process control and environmental compliance. The chemical structure promotes durable finishes and dependable long-term application performance. Within facilities specializing in plating solution processes, the product ensures seamless integration with existing alkaline bath compositions, avoiding interruptions during production.

Deposit Characteristics and Performance Focus
Eco Zinie 300 is formulated to produce a zinc-nickel alloy deposit with high uniformity and surface consistency. The system ensures stable alloy ratios and enhances the resistance properties of the plated surface. By supporting long-term plating operations with minimized fluctuation, the process helps achieve consistent plating thickness and controlled metal transfer. This is particularly valuable for a zinc nickel plating company that prioritizes predictable outcomes and low deviation across large production batches. In electro nickel plating applications, the Eco Zinie 300 process maintains efficient current distribution, contributing to enhanced operational accuracy and chemical stability under continuous use.

Integration with Operational Workflows
The Eco Zinie 300 process is engineered to integrate into standard industrial plating lines without extensive adjustments. It is compatible with automation systems, as well as manually controlled setups requiring high reproducibility. Process engineers can introduce this plating chemical into metal plating service lines focused on alloy coating without modifying core system infrastructure. In environments managed by a zinc nickel plating company, the solution enables process standardization by supporting bath consistency, extending bath life, and maintaining stable coating results over extended cycles. Its alkaline foundation further reduces the risk of imbalance during high-volume operations.

Product Advantages

Structural and System Design Advantages
The Eco Zinie 300 plating solution offers a robust alkaline zinc-nickel chemistry optimized for easy integration within existing plating infrastructure. Its modular additive system, consisting of distinct complexing agents, brighteners, and nickel supplements, allows fine-tuning of deposit characteristics without hardware changes. The process supports continuous filtration cycles that maintain bath clarity and chemical balance, critical for consistent alloy output. Designed for both rack and barrel plating formats, the solution’s adaptability enables seamless deployment across various metal plating service platforms operated by zinc nickel plating companies. Compatibility with standard passivation and cleaning sequences further extends structural reliability.

Enhanced Performance and Operational Usability
Operationally, Eco Zinie 300 provides users with consistent control over alloy composition and deposit appearance, yielding a uniform, bright, and corrosion-resistant zinc-nickel layer. Its broad operating window delivers flexibility to accommodate fluctuations in plating parameters such as current density and temperature, reducing the risk of defects. The formulation is engineered to increase bath life, thereby minimizing chemical consumption and maintenance frequency. Users benefit from straightforward dosing schedules and technical support resources, facilitating efficient process repeatability in both manual and automated electro nickel plating systems. This translates into improved ROI and reduced operational downtime for plating facilities.

Use Scenarios

Continuous Alloy Coating in Industrial Plating Lines
Eco Zinie 300 supports extended-use plating lines that require uninterrupted production schedules and strict deposition control. The process fits into systems running alkaline-based operations, delivering alloy plating with uniform thickness and surface finish. These characteristics benefit metal plating service providers that handle large volumes of parts and components. For any zinc nickel plating company, this solution aids in streamlining continuous processes by reducing manual bath adjustments and stabilizing long-cycle performance without affecting production timelines.

Custom Alloy Finishing in Specialized Facilities
In facilities that offer customized surface treatments or operate in niche application segments, Eco Zinie 300 helps meet specific plating demands without disrupting general process conditions. Its reliable alloy output and chemical stability ensure compatibility with specialized electro nickel plating tasks that demand high accuracy. Whether plating small precision parts or diverse substrate materials, the solution maintains the required alloy integrity. Operators delivering metal plating service in precision-based industries will find this process beneficial for tailoring finishes to varied technical and visual specifications.

Flexible Implementation for System Operators
Eco Zinie 300 allows system managers to implement the process across multiple production formats. Its flexibility supports use in traditional tank-based setups or in more advanced plating systems with integrated controls. Teams working within a zinc nickel plating company can introduce the solution into their workflow without facing adaptation delays. For plating solution applications requiring transition to environmentally friendly and stable formulations, this process provides a compatible and low-disruption upgrade option while maintaining production targets and coating consistency.

About Us

Fengfan was established in 1984 and has accumulated over 40 years of technical expertise in the electroplating industry. The company specializes in the research, development, and manufacturing of plating chemicals for various surface treatment applications. Its product lines serve industries such as automotive, electronics, and precision hardware manufacturing. With a focus on alkaline and alloy plating technologies, Fengfan develops chemical solutions that are tested under rigorous conditions to ensure process reliability. The company integrates formulation development, production, and quality inspection within its facilities. As a zinc nickel plating company, Fengfan provides technical support and reliable product supply to customers worldwide. Its team continues to refine chemical processes to align with market demands for stable, efficient, and environmentally conscious plating operations.

FAQ
What type of process is Eco Zinie 300?
It is an alkaline zinc-nickel alloy plating process designed for controlled and consistent deposition in standard plating systems.

Is this process suitable for electro nickel plating operations?
Yes, it supports electro nickel plating workflows where alloy stability and current distribution are important.

Can Eco Zinie 300 be used in automated metal plating service systems?
Yes, the process is compatible with automated systems used in metal plating service environments and does not require system overhaul.

What kind of company typically uses this plating solution?
The process is commonly used by a zinc nickel plating company that requires stable alloy deposition and reliable plating bath control.

Are special conditions required to implement this process?
The process is formulated for alkaline systems and integrates into standard operations without needing specialized conditions.

Equip your alkaline plating line with Fengfan's Eco Zinie 300 and enhance your alloy control today!
